詳細說明
| 貨號 | 430700500 | 430701000 | 430702000 | 430703000 | 430705000 | 430710000 | |
| 型號 | VP005 | VP010 | VP020 | VP030 | VP050 | VP100 | |
| 額定載荷 | (Ton) | 0.5 | 1 | 2 | 3 | 5 | 10 |
| 測試載荷 | (Kn) | 7.35 | 14.71 | 29.42 | 44.13 | 61.29 | 122.58 |
| 最小轉彎半徑 | (M) | 0.9 | 1.3 | 1.5 | 2 | 2.6 | 2.6 |
| 尺寸 | A | 220 | 220 | 249 | 270 | 300 | 427 |
| B | 174 | 229 | 272 | 304 | 336 | 389 | |
| C | 150 | 179 | 233 | 262 | 302 | 383.5 | |
| D | 35 | 35 | 60 | 60 | 78 | 80 | |
| 推薦用工字鋼 | (mm) | 75-125 | 75-125 | 100-150 | 100-150 | 125-175 | 125-210 |
| 裝箱尺寸 | 整裝 | 310×230×190 | 350×330×250 | 370×330×300 | 400×350×320 | 500×400×400 | / |
| 散裝 | 240×160×120 | 240×190×140 | 280×260×140 | 330×280×180 | 370×330×200 | 470×410×230 | |
| 凈重 | Kg | 6.5 | 10.2 | 18.7 | 30 | 46.3 | 91 |
| 毛重 | Kg | 6.9 | 10.6 | 19.3 | 30.7 | 48 | 98 |
